MOD-31 Nightfighter Modular Powered Bridge

ALL CURRENT ORDERS WILL INCLUDE ONE FREE MINI RAIL THERMAL ARM (Compatible with Flir Breach, Armasight Sidekick, etc.)

Lead Time: 8-12 weeks from order date (contact us with any questions)

Introducing the MOD-31 Nightfighter Modular Powered Bridge

The MOD-31 Nightfighter Modular Powered Bridge is a groundbreaking solution designed to transform your MOD-14 Phantom or MOD-14 Lightfighter monoculars into a cohesive, high-performance binocular system. Engineered for ultimate versatility, this powered bridge seamlessly integrates modular arms, centralized power routing, and customizable fields of view—offering a truly user-configurable night vision platform.

Note: This listing includes the MOD-31 Nightfighter Modular Powered Bridge and your choice of MOD-14 arms (40° or 55°) only. Monocular housings (e.g., MOD-14 Phantom or MOD-14 Lightfighter), image intensifier tubes, lenses, and other accessories are not included.

How It Works with the MOD-14 System

Traditionally, the PVS-14 housing features two electrical contacts near the 1/4-20 mounting interface, originally intended for an auto-shutoff function when used with certain specialized arms and accessories. The MOD-31 Nightfighter bridge repurposes these existing electrical contacts to provide capability for external power input. When a MOD-14 Phantom or MOD-14 Lightfighter monocular is mounted to the Nightfighter bridge, these contacts enable centralized power management and auto shutoff functionality, all without the use of tools. This means:

Centralized Power Control: The bridge can supply power to your monoculars, eliminating the need for separate battery management on each unit.

Auto Shutoff on Articulation: Flip a monocular up to turn it off, flip it down to turn it on—streamlining operation and conserving battery life.

Seamless Power Switching: Monoculars can automatically switch between their internal CR123A batteries and bridge-supplied external power. The Nightfighter bridge can be used with or without a battery in the MOD-14 monoculars.

Key Features

Modular and Adaptable:

MOD-14 Arms: Choose between 40° Standard FOV MOD-14 arms for a classic viewing experience or 55° Wide FOV MOD-14 arms for enhanced peripheral coverage. These arms are specifically designed for use with MOD-14 Phantom or MOD-14 Lightfighter monocular housings.

Tool-Free Attachment: Secure or remove each monocular in seconds using captive thumb screws—no tools required.

Single or Dual Configuration: Easily run a single monocular or configure two monoculars into a binocular-like system. Need to hand off one monocular to a friend or teammate? Detach it in seconds, tool-free, and maintain full functionality for both users.

Customizable Field of View

40° Standard FOV MOD-14 Arms: Maintain the familiar 40° field of view.

55° Wide FOV MOD-14 Arms: Angle the monoculars outward by 7.5° per side, expanding your field of view to a panoramic 55°, increasing situational awareness.

Easy FOV Swaps: Quickly change between 40° and 55° configurations by swapping arms—no need to purchase an entirely new bridge.

Innovative Power Management

Centralized Power Routing: Repurposed PVS-14 electrical contacts enable the bridge to provide power and auto shutoff capabilities.

Auto Shutoff Functionality: Flip up to turn off, flip down to turn on—each monocular articulates independently.

Seamless Power Switching: Monoculars automatically switch between their internal CR123A battery and external power from the bridge.

Interpupillary Distance (IPD) Stops

Precise Adjustments: MOD-14 arms include IPD stops, ensuring a comfortable, repeatable interpupillary distance setting for optimal viewing comfort.

Lightweight and Durable

Ultra-Lightweight Design: The Nightfighter bridge weighs only 2.5 oz, significantly reducing neck strain and fatigue.

Rugged Materials: Crafted from high-strength polymers, anodized aluminum, and stainless steel hardware—built for demanding conditions.

Complete Weight Comparisons

Mil-Spec PVS-14s on standard (non-modular) bridge: 26 - 28 oz

Dual Lightfighters on Nightfighter bridge (Noctis): 19.5 oz

Dual Lightfighters on Nightfighter bridge (RPO 3.0): 16 oz (PVS-31 weight)

Dual Phantoms on Nightfighter bridge (Noctis): 18 oz

Dual Phantoms on Nightfighter bridge (RPO 3.0): 15.5 oz (Under PVS-31 weight!)

These weight reductions are substantial, especially when using ultra-light MOD-14 Phantom housings and lightweight lens configurations, offering unmatched comfort during extended missions.

Future-Proof and Upgradeable

Compatible Today, Upgrade Tomorrow: The MOD-31 Nightfighter bridge currently works with MOD-14 arms and MOD-14 monocular housings. Enjoy this configuration for an ultra fast quick swappable modular system, without the need for any tools.

Dedicated Binocular Configurations (Coming Soon): The upcoming MOD-31 pod toppers will allow direct pod-to-bridge mounting for the MOD-14 phantom, eliminating the need for arms. Transform your setup into a dedicated binocular housing (Nightfighter-AG or Nightfighter-MG) as your needs evolve, without having to invest in a completely new device. Dedicated pod toppers will require a torx tool to complete swap, if user chooses. This configuration is incredibly lightweight, but doesn’t have the flexibility of quick swappable MOD-14 monoculars.

Specifications

Weight (Bridge Only): 2.5 oz

Materials: High-strength polymer, anodized aluminum, stainless steel hardware

Compatibility: MOD-14 Phantom, MOD-14 Lightfighter, or PVS-14 (upgraded with Lightfighter battery compartment)

Arms: Choice of 40° Standard FOV MOD-14 arms or 55° Wide FOV MOD-14 arms (or both)

Power Management: Power routing from Nightfighter bridge CR123 battery compartment

Helmet Mount Compatibility: Dovetail mounts (Wilcox L4 G24, Norotos AKA2/LO-STO, RHINO II with dovetail adapter)

IPD Range: 55 mm to 75+ mm with adjustable IPD stops on MOD-14 arms

What’s Included

MOD-31 Nightfighter Modular Powered Bridge

MOD-14 Arms (Your Choice): Select the 40° Standard FOV MOD-14 arms or the 55° Wide FOV MOD-14 arms. Purchase both sets for maximum versatility.

(Note: Monocular housings, image intensifier tubes, lenses, and other accessories are sold separately.)

Why Choose the MOD-31 Nightfighter Modular Powered Bridge?

A Truly Modular System:
Many users desire a modular bridged monocular system where they can easily hand off one of the monoculars to a friend or partner if needed—previously difficult with systems requiring tools. With the MOD-14 and MOD-31 Nightfighter system, it’s now truly possible—detach a monocular in seconds, no tools required.

Unmatched Lightweight Performance:
Significantly reduce neck strain and operator fatigue during extended missions. Pairing the Nightfighter bridge with ultra-light MOD-14 housings yields a system lighter than many legacy binocular devices.

Advanced Modularity:
Easily adapt to changing mission requirements by switching between monocular and binocular configurations, altering fields of view, or upgrading to a dedicated binocular setup down the line.

Future-Proof Investment:
Upgrade your system as new technology emerges—transition to a dedicated binocular configuration without replacing the entire device, or continue enjoying the benefits of a quick-detach modular system using the MOD-14 arms.

Transferable Lifetime Warranty

We stand behind the quality and durability of our products. The MOD-31 Nightfighter Modular Powered Bridge comes with a Transferable Lifetime Warranty, ensuring peace of mind with your purchase.

Made in the USA

Proudly designed, manufactured, and assembled in the United States.

Currently Restricted to U.S. Sales Only

Due to export regulations, we can only fulfill orders within the United States at this time.

Lead Times & Shipping

Lead Time: Approximately 8-12 weeks from order date.
Shipping: Free domestic shipping within the United States. Contact us with any questions regarding lead times.

Stay Connected

Follow Us on Instagram: @nightvision.plus for product announcements, photos, and videos.

Customer Support

We’re Here to Help: If you have any questions or need assistance, please reach out via our contact page or send us a direct message on Instagram.

Frequently Asked Questions

Q: What is included in this product listing?
A: This listing is for the MOD-31 Nightfighter Modular Powered Bridge and your choice of MOD-14 arms (40° or 55°). Monocular housings, tubes, lenses, and other accessories are not included.

Q: Can I use this bridge with my existing PVS-14?
A: Yes. By upgrading your PVS-14 with the Lightfighter CR123A battery compartment, you gain modular functionality compatible with the Nightfighter bridge.

Q: Can I switch between 40° and 55° MOD-14 arms after purchase?
A: Yes. You can purchase both sets of arms to easily swap configurations.

Q: How will this bridge integrate with upcoming dedicated binocular housings?
A: The Nightfighter bridge will be compatible with MOD-31 pod toppers for the MOD-14 Phantom (available soon), allowing you to create dedicated binocular configurations (Nightfighter-AG or Nightfighter-MG) without using MOD-14 arms. The Nightfighter-AG and Nightfighter-MG will also be available as their own dedicated systems.

Patent Pending
